Today's sharing is byProfessor Wu Zhiyong's Team from Renmin Hospital of Wuhan UniversityA Completed Case of High-Difficulty TEVAR Surgery. The patient had Stanford Type B aortic dissection with complex conditions: the dissection entry was close to the origin of the left subclavian artery (LSA), and the false lumen had already involved the root of the LSA, while the left common carotid artery (LCCA) was adjacent to the LSA, leaving an insufficient proximal anchoring zone; the LSA formed an acute angle with the aortic arch, and its involved ostium was narrowed; the dissection had an extensive range, with a small true lumen and a large false lumen, imposing high requirements on the sealing performance of the stent as well as the deliverability, and flexibility of the delivery system.
In response to these challenges, Professor Wu Zhiyong's team innovatively utilized the Percutek Therapeutics Thoracic Aortic Stent Graft System, successfully completing the in-situ reconstruction of the LSA by instantaneously penetrating the stent graft with a 250T guidewire. This approach precisely overcame technical difficulties such as in-situ fenestration angle control and establishing access through tortuous vessels, ensuring complete closure of the lesion while efficiently restoring blood supply to the LSA. Postoperatively, the patient recovered well, with significant occlusion of the lesion, fully demonstrating the technical advantages of this procedure and the team’s exceptional skill.
'%20fill='%23FFFFFF'%3E%3Crect%20x='249'%20y='126'%20width='1'%20height='1'%3E%3C/rect%3E%3C/g%3E%3C/g%3E%3C/svg%3E)
Gender:Male
Age:56 years old
Chief Complaint:Chest and back swelling pain for 6 hours.
History of Present Illness:The patient experienced sudden chest and back swelling pain, chest tightness, and profuse sweating all over the body 6 hours after lifting heavy objects. The patient visited our hospital's emergency department, and a CTA examination revealed an aortic dissection.
Past Medical History:Hypertension for 3 years.
Detailed Explanation of CTA:Stanford Type B Aortic Dissection, with the tear close to the LSA ostium and the false lumen already involving the root of the LSA; the LCCA is adjacent to the LSA, with a distance of only 2mm; the root of the LSA is involved, and the ostium is narrowed. The true lumen of the dissection is small, measuring only 28.5*11mm, while the false lumen is large, with a maximum size of 38.8*28.5mm. The lesion range is extensive, involving the right common iliac artery and the right internal iliac artery distally; the celiac trunk, superior mesenteric artery, and inferior mesenteric artery are supplied by both true and false lumens, and the bilateral renal arteries are supplied by the true lumen.
Preoperative Three-dimensional Reconstruction
Preoperative CTA Cross-Section
Condition of the Aortic Arch
Stanford Type B aortic dissection, with the tear close to the LSA opening, has already involved the root of the LSA. The proximal anchoring zone is significantly insufficient, and the LCCA is adjacent to the LSA. It is necessary to extend the anchoring zone proximally and reconstruct the LSA.
The lesion range of aortic dissection is large, with a small true lumen and a large false lumen. High demands are placed on the sealing, compliance, and adhesion of thoracic aortic stent grafts, as well as the stability, trackability, and flexibility of the delivery system.
LSA forms an acute angle with the aortic arch, and its root is narrow, which creates difficulties in controlling the fenestration angle during the operation. Additionally, common covered stents on the market are more challenging to fenestrate.
Severe thrombosis at the root of the LSA false lumen requires careful and gentle manipulation.
Surgical Plan Strategy
Endovascular Repair of Thoracic Aortic Stent Graft Directly Covering the Left Subclavian Artery: The procedure is simple and effective, but covering the left subclavian artery may lead to clinical manifestations of posterior circulation ischemia and upper limb ischemia in patients.
Thoracic Aortic Stent-Graft Endovascular Repair + Left Subclavian Artery Chimney Technique: The surgical procedure is relatively simple, but the left subclavian artery is tortuous and narrow, with a higher risk of endoleaks and occlusion, and the mid-to-long-term outcomes are suboptimal.
Endovascular Repair of Thoracic Aortic Stent Grafts with In Vitro Fenestration: Excellent sealing of lesions, preservation of original hemodynamic characteristics, but complex operation. Preoperative modification of the stent is required based on measurement results, which is time-consuming; intraoperative precise alignment and ultra-selective window positioning are required, posing higher risks.
Endovascular Repair of Thoracic Aortic Stent Graft + In-situ Fenestration: Effective sealing of the lesion, no preoperative stent modification required. However, traditional in-situ fenestration of aortic stent grafts demands advanced interventional devices, such as in-situ fenestration needles, lasers, biopsy needles, and other specialized membrane-puncturing instruments.
The Hua Mai thoracic aortic stent graft can perform in-situ fenestration using the soft tip of a CTO guidewire. Considering the mid-to-long term treatment outcomes and the simplicity of intraoperative manipulation, after comprehensive evaluation, Professor Wu Zhiyong's team chose Hua Mai • Tianyi.®Endovascular repair of the thoracic aorta with a covered stent graft and reconstruction of the left subclavian artery using in-situ fenestration technology.
01. The patient was placed in the supine position, followed by routine disinfection and draping. After general anesthesia, the Seldinger technique was used to puncture the left brachial artery and left femoral artery, and sheaths were inserted. Aortography revealed a Stanford Type B aortic dissection, with the primary tear near the ostium of the left subclavian artery (LSA), a small true lumen, and a large false lumen.
Abdominal Aortic Angiography
Ascending Aortography
02. Through the left brachial artery, an 8.5F steerable sheath was exchanged, and a pigtail catheter was advanced into the ascending aorta. Through the left femoral artery, a yellow-marked pigtail catheter was introduced into the ascending aorta, and its position was adjusted to be located on the anterior wall.
03. A Percutek Therapeutics thoracic aortic stent graft PTBS3026180 was implanted in the left femoral artery. The proximal end of the stent graft was positioned distal to the LCCA opening, covering the LSA. After controlling blood pressure, the stent was released with good morphology.
Implantation of Percutek Thoracic Stent
Release of Percutek Therapeutics' Thoracic Stent
04. A 250T guidewire was inserted into the left brachial artery and successfully punctured the membrane with the assistance of a steerable sheath and a steerable catheter.
250T Guidewire Successfully Penetrates Membrane
05. Sequentially dilate the fenestration using 3*30mm, 5*30mm, 6*20mm Sterling balloons and 5*40mm, 8*40mm Mustang balloons.
3*30mm Balloon Dilation Window
5*30mm Balloon Expandable Window
6*20mm Balloon Dilatation Window
5*40mm Balloon Dilation Window
8*40mm Balloon Dilation Window
06. Through the balloon-sheath technique via the aortic fenestration site, a self-expanding covered stent 10*40mm was implanted in the LSA. After fluoroscopic positioning, the stent was released. Angiography showed that blood flow in the thoracic aorta and its branches was unobstructed.
LSA Branch Stent Implantation
07.Postoperative angiography showed that the blood flow of the branches above the aortic arch was unobstructed, and the main stent and branch stents were in good position. No opacification was observed in the thoracic aortic dissection, with no significant endoleak. The blood flow in the abdominal aorta and its branches remained unobstructed.
Postoperative Thoracic Angiography
Postoperative Abdominal Aortic Angiography
08.Withdraw all guidewires, catheters, and sheaths. Apply pressure dressing to each puncture site. Procedure completed.
Summary of Case Experience
This case study involves a patient with Stanford Type B aortic dissection, where the tear is close to the left subclavian artery (LSA). The false lumen is large and has already extended to the root of the LSA, with an insufficient proximal anchoring zone. The true lumen is small and tortuous, posing extremely high demands on the stability, deliverability, and flexibility of the stent delivery system, as well as the sealing capability, conformability, apposition, and minimal elastic recoil of the covered stent. Therefore, the primary challenge of the surgery lies in effectively sealing the lesion while ensuring the patient's long-term prognosis.
In response to these challenges, Professor Wu Zhiyong's team implemented targeted measures and chose Percutek Therapeutics.®The thoracic aortic stent graft system was used for treatment. During the procedure, the fenestration of the thoracic aortic stent graft was easily completed using only a 250T guidewire. The stent graft covering at the fenestration site was easy to penetrate and expand, and the balloon dilation process was simple, safe, and reliable, efficiently and safely achieving supra-arch reconstruction of the LSA. Postoperatively, the stent showed good morphology with significant lesion sealing, and the patient had a favorable prognosis. The supra-arch reconstruction outcome met preoperative planning expectations, fully demonstrating the team's excellent technical skills and extensive clinical experience.
